Gunite Equipment & Supply C-10HDD

Gunite Equipment & SupplC-10HHD

The C-10HHD is a rotary bowl-type dry-mix gunite machine, powered by a power take-off (PTO) connection. Designed for demanding environments such as tunnelling, mining, refractory spraying and concrete remediation, these pumps deliver reliable performance and consistent output. The C-10SL gunite machine offers a heavy-duty design and powerful output, making it the preferred choice for contractors across the world.

C-10HHD gunite machines are typically used with batch plants, which provide a PTO to the motor on the shotcrete machine. The hydraulic motor reduces the overall amount of air needed to power the machine. Features include a premium-life feed system, moulded discharge liner and exhaust suppression chamber. A tilt-hopper provides easy access for cleaning and setup. All units include air line regulating valves and choice of high or medium-production feed system.

Each machine is supported with local servicing, parts, and operator training to keep your projects moving.

CGS also offers the pneumatic model (C10SL) in our hire fleet for short-term project requirements.

Contact us today to discuss the gunite machine that stands the test of time.

Enquire Now

Features

Shipping Dimensions 51 × 51 × 59 in
Max Output 15 yd3/hr (11.5 m3)
Motor Hydraulic
Air Compressor Req 365-900 cfm
Hydraulic Power Req Min 12 gpm at 1,800 psi
Water Source Req 50 psi / 420 gph flow rate
Feed System Included
Hinged Hopper Yes
External Lubrication Yes
Drive System Direct
Outlet Size 1/5 to 2 in.
Max Aggregate 3/4 in. minus (19 mm)
Max Vertical 300 ft (91 m)
Max Horizontal 1000 ft (300 m)
Product Dimensions 28 x 37 x 41 in. (W x L x H)
Weight 740 lb (335 kg)

Applications

  • Refractory
  • Shotcrete
  • Gunite
  • Tunnels
  • Concrete Repair
  • Buildings
  • Excavations
  • Slope Stablisation
  • Rockscaping
  • Pools
  • Mines
  • Channels
  • Piers
  • Sea Walls
  • Sewers
  • Parks & Zoos
  • Retaining & Fire Walls
  • Dams & Reservoirs
  • Sand & Rock Backfill
  • Concrete Pipe
  • Ditches
